K10CR1 Cage Rotation Stage
Max. Vel. (Trig HI) – The output trigger goes high (5V) when the stage reaches max
velocity (as set using the SetVelParams method).
Max. Vel. (Trig LO) – The output trigger goes low (0V) when the stage reaches max
velocity (as set using the SetVelParams method).
Persist Settings to Hardware
Many of the parameters that can be set for the K10CR1 stages can be stored
(persisted) within the unit itself, such that when the unit is next powered up these
settings are applied automatically. This is particularly important when the driver is
being used manually in the absence of a PC and USB link. The button parameters
described above are good examples of settings that can be altered and then persisted
in the driver for use in absence of a PC. To save the settings to hardware, check the
‘Persist Settings to Hardware’ checkbox before clicking the ‘OK button.
Caution
The ‘Persist Settings’ functionality is provided to simplify use of the unit
in the absence of a PC. When the unit is connected to a PC and is
operated via APTUser, the default APTServer settings will be loaded at
boot up, even if the ‘Persist Settings’ option has been checked.
