K10CR1 Cage Rotation Stage
A.2 Design Specification
Parameter Value
Base Material Aluminum
Bearing Type 4-point Ball Bearing
Drive Mechanism Worm Gear, Ratio 1:120
Homing Limit Switch Hall Effect
Central Aperture SM1 Threaded
Operating Temperature Range 5 to 40°C (41 to 104°F)
Motor Type 2-Phase Stepper Motor
Motor Drive Voltage 8 V Nominal
Terminal Resistance 20
Output Power 2.5 W Nominal
Step Size 1.8 °
Rotor Inductance 4.2 mH per Phase
Dimensions (L x W x H)) 107 mm x 66.0 mm x 21.5 mm
(4.21” x 2.6” x 0.84”)
Weight 0.22 kg
