-16-
QtyDescription
名稱
1
2
2
1
1
1
1
1
1
1
2
No.
1
2
3
4
5
6
7
8
9
10
11
METAL TAIL UNIT HOUSING
FLANGE BEARING
, d5xD13xW4
BEARING, d12xD18xW4
COLLAR, d16.5xD18xW6.83
COLLAR, d12xD13xW6.85
TAIL INPUT BEVEL-A(24T)
TAIL OUTPUT BEVEL-B(24T)
PIN, d2x12
SET SCREW, M3x4
TAIL LEVER BKT
SOCKET SCREW, M2.5x8
金屬尾座
凸緣軸承, d5xD13xW4
滾珠軸承, d12xD18xW4
尾座軸承間隔環
, d16.5xD18xW6.83
尾傘齒軸環
, d12xD13xW6.85
尾螺旋傘齒輪A(24T)
尾螺旋傘齒輪B(24T)
軸承滾針
, d2x12
無頭內六角螺絲, M3x4
金屬尾控制臂座
內六角螺絲, M2.5x8
Tail Rotor System /
尾旋翼機構組裝
Apply threadlocker
使用螺絲防鬆膠
No.
12
13
14
15
16
17
18
19
20
21
QtyDescription
名稱
TAIL PITCH CONTROL LEVER
BEARING, d4xD7xW2.5
WASHER, d3xD5xW0.5
COLLAR, d3xD4xW10
SOCKET SCREW, M3x14
LINKAGE BALL(B)
CARBON TAIL BLADE
LOCK NUT, M3
SOCKET SCREW, M3x20
WASHER, d5xD8xW0.15
尾旋翼控制桿
滾珠軸承, d4xD7xW2.5
墊片
, d3xD5xW0.5
軸環
, d3xD4xW10
內六角螺絲, M3x14
內六角連接頭自攻螺絲(B)
碳纖尾旋翼
止鬆螺帽
, M3
內六角螺絲, M3x20
墊片, d5xD8xW0.15
1
2
1
1
1
1
2
2
2
1
Ensure the leading edges
of the blades are toward
correct side as shown.
請確認旋翼前櫞朝向正確方向(如圖示)。
Bag H
Apply grease
使用潤滑油膏
Ensure smooth, non-binding
movement when assembling
確認組件靈活度
BEARING, d12xD18xW4
滾珠軸承
, d12xD18xW4
FLANGE BEARING, d5xD13xW4
凸緣軸承
, d5xD13xW4
COLLAR, d16.5xD18xW6.83
尾座軸承間隔環
, d16.5xD18xW6.83
COLLAR
, d12xD13xW6.85
尾傘齒軸環, d12xD13xW6.85
PIN, d2x12
軸承滾針, d2x12
SET SCREW, M3x4
無頭內六角螺絲
, M3x4
SOCKET SCREW, M2.5x8
內六角螺絲, M2.5x8
BEARING,
d4xD7xW2.5
滾珠軸承,
d4xD7xW2.5
WASHER
, d3xD5xW0.5
墊片
, d3xD5xW0.5
LINKAGE BALL(B)
內六角連接頭自攻螺絲(B)
COLLAR, d3xD4xW10
軸環, d3xD4xW10
SOCKET SCREW, M3x14
內六角螺絲, M3x14
LOCK NUT, M3
止鬆螺帽, M3
SOCKET SCREW, M3x20
內六角半牙螺絲, M3x20
WASHER,
d5xD8xW0.15
墊片,
d5xD8xW0.15
Check the mesh of gears (#6 & #7), please add the
washer (#21) for a proper mesh if too much play.
請檢查齒輪間隙(#6及#7)，間隙過大時請酌加墊片(#21)。
(18)
(17)
(20)
(16)
(12)
(13)
(13)
(19)
(9)
(7)
(21)
(8)
(14)
(15)
(19)
(20)
Secure all screws shown on this page with a drop of threadlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
Apply some of silicon
oil or grease onto the
gears.
(Using PV0269
Grease for Plastic Parts is
recommended.)
在傘齒輪上塗抹些許矽膠
油或塑膠零件潤滑油
(推薦使用PV0269塑膠
零件潤滑油)。
(11)
(6)
(10)
(3)
(1)
(2)
(2)
(4)
(5)
(3)
To Next Page
