THUNDER TIGER raptor e700 - Servo Installation; 伺服機裝配

-18-
Servo Installation / 伺服機裝配
Bag K
Apply threadlocker
使用螺絲防鬆膠
Must be purchased separately
改裝品需另購
No.
1
2
3
4
5
6
7
8
QtyDescription
名稱
連接球座
伺服機墊片
伺服機螺帽
伺服機固定片
伺服機固定座
伺服機擺臂軸套
伺服機擺臂
尾舵伺服機擺臂
LINK BALL
SERVO MOUNTING
SERVO NUT
SERVO MOUNTING
SERVO BED
SERVO HORN COLLAR
SERVO HORN
RUDDER SERVO HORN
6
6
6
2
2
4
3
1
No.
9
10
11
12
13
14
15
QtyDescription
名稱
內六角連接頭螺絲(A)
無頭內六角螺絲, M3x3
內六角螺絲, M2.5x6
半圓頭內六角螺絲
, M3x5
扁圓自攻螺絲(粗) , M2.6x10
扁圓自攻螺絲(粗) , M2.6x14
星型低頭螺絲 , M3x8
LINKAGE BALL(A)
SET SCREW, M3x3
SOCKET SCREW, M2.5x6
BUTTON HEAD SOCKET SCREW, M3x5
BUTTON PHILLIPS TAPPING SCREW, M2.6x10
BUTTON PHILLIPS TAPPING SCREW, M2.6x14
TORX SCREW, M3x8
1
4
4
4
4
12
4
The adaptors come with the kit are applicable to ACR RC /
Futaba servos as standard parts. The option adaptors for JR or
Hitec are also available separately:
內附標準伺服機擺臂軸套適用於ACE RC及Futaba伺服機。
JR或Hitec伺服機使用之軸套可另外購買：
No.PV1623-J Servo Horn Adaptor for JR 伺服機擺臂軸套, JR
No.PV1623-H Servo Horn Adaptor for Hitec 伺服機擺臂軸套, Hitec
LINK BALL
連接球座
LINKAGE BALL(A)
內六角連接頭螺絲(A)
BUTTON PHILLIPS
TAPPING SCREW
, M2.6x10
扁圓自攻螺絲(粗) , M2.6x10
BUTTON PHILLIPS
TAPPING SCREW , M2.6x14
扁圓自攻螺絲(粗) , M2.6x14
TORX SCREW, M3x8
星型低頭螺絲, M3x8
SET SCREW, M3x3
無頭內六角螺絲, M3x3
SOCKET SCREW, M2.5x6
內六角螺絲, M2.5x6
(1)
(2)
(14)
(6)
(11)
(7)
(10)
(12)
Do not tighten the screw #11 & #10 at
this step for preforming servo of
calibations later.
螺絲#11 & #10暫勿鎖緊以
便後續中立點調整。
(2)
(3)
(3)
(15)
(13)
(4)
(4)
(1)
(7)
(6)
(11)
(10)
(5)
(5)
(12)
(13)
(6)
(2)
(2)
(9)
(8)
(3)
(3)
(11)
(14)
(12)
(14)
(10)
BUTTON HEAD
SOCKET SCREW, M3x5
半圓頭內六角螺絲, M3x5
