DECALS
C190-0113 01.07.2019 Rev: 4.0
Warning.
Hot exhaust
Danger.
Rotating blades.
Keep hands and feet out.
Warning.
High velocity discharge -
keep clear
Reverse feed
Personal Protective
Equipment required.
See page 5.
Forward feed
Read the instruction manual
for greasing and
maintenance information.
Warning. Do not engage starter
motor for more than 20 seconds.
Allow one minute before
attempting to start. Investigate
reasons for failure to start.
Excessive cranking will result in
starter motor failure. This will
not be covered under warranty.
The instruction manual with
this machine contains
important operating,
maintenance and health and
safety information. Failure
to follow the information
contained in the instruction
manual may lead to death or
serious injury.
Lifting eye is designed to lift the
machine’s weight only. Do not
use hoist hook directly on lifting
eye. Use correctly rated safety
shackle only through lifting eye.
Lifting eye to be inspected every
6 months or before each use.
Always visually inspect lifting eye
prior to each use. Do not use
lifting eye if damaged.
Push safety bar to stop.
Do not pull here.
Clean under blades before
refitting or turning. Failure to do
so may result in blade(s) coming
loose and damage being caused
to the rotor housing.
Fuel Here.
Risk of fire. Allow engine to
cool for 1 minute before
refuelling.
Use diesel fuel only.
New drive belts need re-
tensioning.
When new belts are fitted check
tension every 2-3 hours & adjust
until tension remains constant.
Torque blade bolts to 125 lbs ft
(170 Nm).
When the engine stop
button is pressed it must be
pulled out again and the
ignition switch turned off to
reset the machine before
attempting to restart.
Track
Chip
Select Chip mode when adjusting
track width.
DECAL DESCRIPTION
616
617
670
1661
1662
4099
2800
2949
3022
1399
P691
19517
18393
2801
Push to stop,
Pull to reset.
(engine)
P1301
P1812
19518
1745
17450
C192-0112
