Tinius Olsen MP1200 Extrusion Plastometer Page 4-5
Operation Manual # 02002215
4.14 Semi-Automatic Pneumatic Purge & Clean
The Semi-Automatic Pneumatic Purge and Cleaning Assist Attachment can be used only on
MP1200M models equipped with WLD (Weight Lowering Device). The assembly is attached to
the WLD and will allow users to purge the test charge to a predetermined starting point. The
operator will charge the material into the bore and start the test, lowering the WLD weight
platform to a predetermined height (determined by manually programming the MP1200
controller or using Horizon software). The purge feature is then engaged, applying a downward
force on the weight to purge the material from the bore until the weight is stopped by the weight
platform. At the end of the pre-programmed release time period, the weight platform fully
lowers and the test will continue normally until its conclusion. At the end of the test, the purge
feature can be activated to purge any remaining material from the bore. After the WLD is raised
to its top position and swings out of the way, the piston can be removed from the cylinder using
the Piston Extraction Tool (included). After the orifice (die) is removed, a cleaning rod is placed
in position by the technician. Cleaning patches are then placed over the bore and the ram is
activated, helping the operator to clean the bore.
P/N: 02002102 - (New Machine)
P/N: 02002217 - (Existing Machine)
4.15 Horizon Data Acquisition & Machine Control Software
Tinius Olsen’s Horizon Software Packages are available for connecting a single Melt Indexer or
up to ten Melt Indexers to a computer. Consult the factory or your local representative for
complete details.
P/N: 02001672 Software – Horizon MFI Primary Platform
P/N: 21001127 Software - Horizon- Multiple Machine Package
4.16 Orifice (Die) Options
P/N: 02001030 – Orifice, D2 tool steel (ASTM D 1238, ISO 1133)-Standard
P/N: 02001268 – Orifice, Carbide 0.0413” ID x 0.157” L (“Half Die”)
P/N: 02001033 – Orifice, Carbide (PVC, ASTM D3364)
P/N: 02001032 – Orifice, Stainless Steel (PVC, ASTM D3364)
P/N: 02001031 – Orifice, Carbide (ASTM D 1238, ISO 1133)
P/N: 02001167 – Orifice, Stellite 6B (ASTM D 1238, ISO 1133) corrosion resistant
4.17 Piston Rod Options
P/N: 02002163 - ASTM Piston Rod
P/N: 02002164 - ISO (only) Piston Rod
P/N: 02002165 - Combination ASTM/ISO Piston Rod)
P/N: 02002149 – Guide Collar, MP1200
Note: The piston rods listed above are for the MP1200 model only. Piston rods from the
MP600 and older models will not work with the MP1200.
