Tinius Olsen MP1200 Extrusion Plastometer Page 5-1
Operation Manual # 02002215
5 Section 5 – Set-Up and Installation
NOTE: Instructions in this Section cover basic machine setup. For instruction on installing and
operating optional accessories supplied with the unit, please refer to the appropriate Section of this
manual.
CAUTION: This machine is designed for indoor use only. It shall be used in a controlled
environment (temperature range 5
°
C to 40
°
C (40 to 100
°
F), maximum R.H. of 80% at 31°C).
Maximum operating altitude is 3,200 meters (10,000 feet).
CAUTION: In some instances an exhaust system may be used to remove the excess heat
and/or fumes/odors released during a test. These instructions do not address all of the
safety concerns related to ventilation of fumes produced during normal testing operations.
5.1 Unpacking the Machine
Locate the packing list and carefully uncrate and remove all packing material from around
the machine. Carefully remove the machine from the crate. Check all parts and accessories
against the packing list.
CAUTION: The machine is heavy and care must be used when lifting the machine from the
box or moving the machine. Always lift the machine by the base plate. Never pick the
machine up by the Motorized Weight Lowering Device (WLD) or by the furnace assembly.
It is advisable to retain all packing materials until the machine has been installed and
commissioned.
5.2 Locating the Machine
Place the machine on a sturdy, level surface. Place the machine in an area that is free from
vibrations. Place the tools on the rack on the right hand side of the machine.
The basic machine is shipped fully assembled (the operator has to attach the PPDT if you
ordered one). There is some assembly required for optional accessories.
5.3 Leveling the Machine
Insert the orifice in the cylinder, and then insert the piston assembly. Place the precision
level over the top of the piston. The piston rod must be straight and the base of the level
seated cleanly on the shoulder of the piston. Level the machine using the screw adjustment
feet on the corners of the base plate. Verify that the machine is level by rotating the level
only and then the piston assembly only. At all level positions, no more than half of the
bubble will be outside the circle. Remove the precision level from the piston and store it in a
safe place. Turn the machine ON using the switch on the right side of the machine.
Depending on the model, one of the two main screens will appears.
