Tinius Olsen MP1200 Extrusion Plastometer Page 8-1

Operation Manual # 02002215

8 Section 8 – Printer (Optional)

8.1 Certain USB printers may be attached to the MP1200. Tinius Olsen does not sell printers at

this time.

8.2 The following printers have been checked for proper operation with the MP1200

HP OfficeJet 6000 (Model E609A)

HP OfficeJet 6500A
