TIPTEL 3240 - 5.23. Security->Basic


URL: Auto provisioning server address.

User name: Configure if server needs an username to
access, otherwise left blank.

Password: Configure if server needs a password to
access, otherwise left blank.

Common AES Key: Used for IP phone to decipher
common Auto Provisioning configuration file.

AES Key(MAC): Used for IP phone to decipher
MAC-oriente
d auto provisioning configuration file(for
example, file name could be 0c1105888888.conf if IP
phone’s MAC address is 0c1105888888).
Note: AES is one of many encryption, it should be configure
only configure filed is ciphered with AES, otherwise left blank.
AutoP
To display and configure Auto Provisioning mode settings.
This Auto Provisioning mode is actually self-explanatory.
For example, mode “Power on” means IP phone will go to do
Provisioning every time it powers on.
System Log
To display syslog level and export syslog file.
Syslog level: From level 0~7.The higher level means the more
specific syslog is saved to a temporary file.
By default, it’s level 3.
Export Log: Click to export temporary syslog file to local PC.
PCAP
To start, stop packets capturing or to export captured Packet
f i le .

Start: To start capturing all the packets file sent or
received from IP phone.
 Stop: To stop capturing packets.
Note: IP phone will save captured packets file to a temporary
file, this file maximum size is 1M(mega bytes), and will top
capturing once reaching this maximum size.
Others
To display or configure others features from this page.
Config file: To export or import configure file for IP phone.
5.23.Security->Basic
Path: Web UI->Security->Basic
