1200-1600 Series Rotary Cutters 22 Titan Implement, LLC
August 2016 (423) 334-0012
4. Nomenclature
4.1 Description and Intended Use
The rotary cutters are designed for light duty
applications such as weed, grass, and light brush up to
a 3” diameter. These cutters use a single spindle with
two free-swinging blades, which reduce the shock of
impact when a stationary object is contacted. A shear
bolt through the input shaft or a slip clutch, if equipped,
protects the gearbox and driveline from damage.
Standard equipment includes driveline shields and
clutch shields. Front and rear chain discharge shields
are optional.
4.1.1 Owner/Operator Manual Storage
Always store the Owner/Operator manual and other
operating materials in the document storage tube.
