28. Apply grease to the zerk on the tailwheel fork.
29. Apply grease to the zerk on the tailwheel hub.
5.3 Installation and Removal of Driveline
to Tractor PTO
WARNING
Entanglement Hazard
To avoid serious injury or death from
driveline contact:
Shut off tractor PTO and disengage before
dismounting.
Do not operate PTO if shields are missing or
damaged.
Keep hands, feet, and body away from rotating
parts.
To install the driveline:
1. Turn the tractor off , set the parking brake, and
remove the key.
2. Depress the locking pin on the tractor end of the
driveline.
3. Push the driveline onto the tractor PTO shaft until
the locking pin engages.
To remove:
1. Depress the locking pin on the tractor end of the
driveline.
2. Slide the driveline off the tractor PTO shaft.
