Titan Implement, LLC 59 1200-1600 Series Rotary Cutters
(423) 334-0012 August 2016
1500 Series Cutters
Item Part Number Description Qty.
1 140003 A-Frame,Right Side (1505, 1506) 1
2 140002 A-Frame, Left Side (1505, 1506) 1
3 150030
A-Frame, Right Side, Heavy Duty
(1507)
1
4
150032 A-Frame, Left Side, Heavy Duty
(1507)
1
5 110032 Lift Pin Kit, CAT l (1505, 1506) 2
5a 120005
Lift Pin Bushing, 1/2” x 1-1/4” OD x
7/8” ID
2
6 150033 Lift Pin Kit, CAT ll (1507) 2
6a 150550 Lynch Pin (1507) 2
7 120006 Knuckle, Wing Style 2
8
150044
150045
150047
150048
A-Frame Knuckle Bolt & Locknut Kit,
3/4-10 x 5-1/2” (1505, 1506)
A-Frame Knuckle Bolt & Locknut Kit,
5/8-11 x 5-1/2” (1505, 1506)
A-Frame Knuckle Bolt & Locknut Kit,
3/4-10 x 5-1/2” (1507)
A-Frame Knuckle Bolt & Locknut Kit,
5/8-11 x 5-1/2” (1507)
1
9——
10 110015
Back Brace Rear Bolt & Locknut Kit,
5/8-11 x 2”
2
11
110031
150036
Back Brace, 3/8” X 2” X 36” (1505,
1506)
Back Brace, 3/8” X 2” X 50” (1507)
2
12
110030
150051
A-Frame Spacer, 2” (1505, 1506)
A-Frame Spacer, 2-1/4” (1507)
2
1600 Series Cutters
Item Part Number Description Qty.
1——
2——
3 160009
A-Frame, Left or Right Side, Heavy
Duty (1606, 1607)
2
4——
5——
5a — —
6 150033 Lift Pin Kit, CAT ll (1606, 1607) 2
6a 150550 Lynch Pin (1606, 1607) 2
7 120006 Knuckle, Wing Style 2
8
150047
150048
A-Frame Knuckle Bolt & Locknut Kit,
3/4-10 x 5-1/2” (1606, 1607)
A-Frame Knuckle Bolt & Locknut Kit,
5/8-11 x 5-1/2” (1606, 1607)
1
1
9 150034
A-Frame Bottom Bolt & Locknut Kit,
3/4-10 x 2-1/2” (1606, 1607)
2
10 110015
Back Brace Rear Bolt & Locknut Kit,
5/8-11 x 2” (1606, 1607)
2
11 160023
Back Brace, 1/4” X 2” X 50”
(1606, 1607)
2
12 110030
A-Frame Spacer, 2” (1606, 1607)
2
