1200-1600 Series Rotary Cutters 64 Titan Implement, LLC
August 2016 (423) 334-0012
1400 Series Cutters
Item Part Number Description Qty.
1
140000
140001
Gearbox, Shear Pin, 75 HP
Gearbox, Slip Clutch, 75 HP
1
2 110003 Snap Ring, 1-3/8” 1
3
110004
110068
Gearbox Bolt, Lockwasher & Locknut
Kit, 5/8-11 x 2”
Gearbox Bolt, Lockwasher & Locknut
Kit, 3/4-10 x 3”
1
4
110005
120001
Gearbox Shield - Shear Pin
Gearbox Shield - Slip Clutch
1
5 110006
Gearbox Shield Bolt & Lockwasher
Kit, 5/16-18 x 1/2” (4 each)
1
6 110007
Shear Pin Bolt & Locknut Kit, 1/2-13 x
3” Grade 2 (5 each)
1
7 110008 Gearbox Vent Plug 1
8 110009 Gearbox Drain Plug 1
9 190001 Retaining Bolt - Slip Clutch 1
1500 Series Cutters
Item Part Number Description Qty.
1
130000
150026
Gearbox, Slip Clutch, 100 HP
(1505, 1506)
Gearbox, Slip Clutch, 150 HP (1507)
1
———
3 110068
Gearbox Bolt, Lockwasher & Locknut
Kit, 3/4-10 x 3”
1
4
120001
150028
Gearbox Shield - Slip Clutch
Gearbox Shield - Metal (1507)
1
5
110006
110017
Gearbox Shield Bolt & Lockwasher
Kit, 5/16-18 x 1/2” (4 each)
Gearbox Shield Bolt & Lockwasher
Kit, 1/2-13 x 1-1/2” (3 each) (1507,
1606, 1607)
1
———
7 110008 Gearbox Vent Plug 1
8 110009 Gearbox Drain Plug 1
9 190001 Retaining Bolt - Slip Clutch 1
1600 Series Cutters
Item Part Number Description Qty.
1 130000 Gearbox, Slip Clutch, 100 HP 1
———
3 110068
Gearbox Bolt, Lockwasher & Locknut
Kit, 3/4-10 x 3”
1
4 160008
Gearbox Shield - Slip Clutch - Metal
(1606, 1607)
1
5 110017
Gearbox Shield Bolt & Lockwasher
Kit, 1/2-13 x 1-1/2” (3 each)
(1606, 1607)
1
———
7 110008 Gearbox Vent Plug 1
8 110009 Gearbox Drain Plug 1
9 190001 Retaining Bolt - Slip Clutch 1
