TKH KEYPROCESSOR Orion User Manual

17
Power measurement reader
Yes
Power consumption readers
Yes
H1 and H2 overload detection
Yes
6.3.2 Orion – RS485 bus communication (kpBus)
Type of controller
connected:
Polyx, Pluto
Number
Connection
Digital input
2
T1, T2
Digital output
8
O1, O2, O3, O4, O5, O6, H1 and H2
Monitored inputs (ADC)
6
A1, A2, A3, A4, A5, A6
Orion override input
1
T
Wiegand/ABA card reader
2*
LD, D0, D1, C and V+
kpSensor
2**
C, S
Location buzzer
Yes
Status LED
Yes
MicroSD card
For emergency card use
RJ45 – PRT2
kpBus communication
Indoor temperature sensor
Yes
Power supply measurement
Yes
Power measurement reader
Yes
Power consumption readers
Yes
H1 and H2 overload detection
Yes
6.3.3 Orion – functional replacement for the Orbit
reader
Type of controller connected:
iPU-8, Polyx or Pluto
Number
Connection
Digital input
8
A1, A2, A3, A4, A5 A6, T1, T2
Digital output
4
H1, H2, O2, O5
Wiegand/ABA card reader
2
LD, D0, D1, C and V+
Status LED
Yes
RJ45 – PRT1
RS422 communication with controller
Indoor temperature sensor
Internal only
Power supply measurement
Internal only
Power measurement reader
Internal only
Power consumption readers
Internal only
H1 and H2 overload detection
Internal only
* D0 and D1 are shared inputs. If no card reader is used, D0 and D1 can be used as digital
inputs.
** Only the combined Temperature & Humidity sensor supplied by Keyprocessor is supported.
