TKH KEYPROCESSOR Orion User Manual

32
7.5 Default inputs and outputs
The Orion’s inputs and outputs are described below.
Reader & IO-1:
Reader & IO-2:
7.5.1 Monitored inputs (A1 – A6)
When using monitored inputs (ADC), a certain state of the input can be determined by one or
more resistance values. This includes a detection of tampering or intrusion detector sabotage.
Default input types are:
- NO - Normally open
- NC - Normally closed
- Blocked
- EOL (End Of Line)*
- DEOL (Dual End Of Line)*
- DEOL inverted*
- TEOL (Triple End Of Line)*
- TEOL inverted*
* Recommended resistor values: EOL: 4k7 or 5k6 and Masking 22K
Symbol
Description
iProtect default
T1
Digital input
Door in latch mode
D0
D0 / Data or Digital input*
D1
D1 / Clock or Digital
input*
O1
Digital output
A1
Monitored input 1
Loop / Enable
A2
Monitored input 2
Button
A3
Monitored input 3
Door mode
H1
High Power output
Door operation
O2
Digital output
Alarm
O3
Digital output
Symbol
Description
iProtect default
T2
Digital input
Door in latch mode
D0
D0 / Data or Digital input*
D1
D1 / Clock or Digital input*
O4
Digital output
A4
Monitored input 4
Loop / Enable
A5
Monitored input 5*
Button
A6
Monitored input 6*
Door mode
H2
High Power output
Door operation
O5
Digital output
Alarm
O6
Digital output
