TKH KEYPROCESSOR Orion User Manual

33
Resistor values
NC
NO
EOL
Sabotage
DEOL
DEOL
inverted
TEOL
TEOL
inverted
0 – 699
Idle
0 – 699
Active
0 – 699
Sab. Closed
0 – 699
Sab. Closed
0 – 699
Sab. Closed
0 – 699
Sab. Closed
0 – 699
Sab. Closed
700 – 60K
Active
700 – 60K
Idle
700 – 6999
Idle
700 – 6999
Idle
700 – 6999
Active
700 – 6999
Idle
700 – 6999
Active
7K – 60K
Sab. Open
7K – 14999
Active
7K – 14999
Idle
7K – 14999
Active
7K – 14999
Idle
15k – 60K
Sab. Open
15k – 60K
Sab. Open
15k – 40K
Masking
15k – 40K
Masking
40k – 60K
Sab. Open
40k – 60K
Sab. Open
Contact
GND
Input
NO
Contact
GND
Input
NC
Contact
Input
GND
EOL
Sabotage
Input
GND
TEOL
Anti Mask
Contact
Alarm
Contact
DEOL
Input
GND
Alarm
Contact
Alarm
Contact
Input
GND
DEOL
inverted
Alarm
Contact
TEOL
inverted
Anti Mask
Contact
Input
GND
