TKH KEYPROCESSOR Orion User Manual

53
12.2 Orion
Housing
Measurements:
110.0 x 47.0 x 93mm (L x W x H)
Weight:
0,25 Kg
Mounting
Dinrail
35mm DIN rail type O profile
Communication
PRT1
RJ45 socket, RS422
Pin out
Pin 1 = RXB Pin 5 = GND
Pin 2 = RXA Pin 6 = TXB
Pin 3 = TXB Pin 7.8 = GND
Pin 4 = 12V dc
PRT2
RJ45 socket, RS485
Pin out
Pin 1 = RXB Pin 5 = GND
Pin 2 = RXA Pin 6 = RXA
Pin 3 = RXB Pin 7.8 = GND
Pin 4 = 12V dc
Card reader
Reader power (+V)
Voltage
12.0V DC
Current
500mA (one Polyfuse for both readers)
Interface
Clock/Data
depending of used cable and card reader
Wiegand
depending of used cable and card reader
Power supply & consumption
Voltage (+)
12,0 – 24V DC
Power
Average
0.48W (no load)
Digital I/O
Tamper
Switching to GND
Digital output
O1, O2, O3, O4, O5, O6
Max. Voltage 28V; Open collector output; sink current. Max.
current 300mA (Polyfuse)
High power output H1, H2
Switching to GND, max. 2.5A
Digital input T1, T2
Switching to GND, <20K ohm
Digital input D0/D1
Reader IO-1
Switching to GND, <20K ohm
Digital input D0/D1
Reader IO-2
Switching to GND, <20K ohm
Monitored inputs
A1, A2, A3, A4, A5, A6
value
0-60K ohm. Response time <250ms
Switching to GND, <2K ohm. Response time
20ms
Environment sensor
kpSensor
Sensor
kpSensor
2
Type
Temperature/Humidity
Indicators
Visual
RGB-LED
Sound
Multi-tone buzzer
MicroSD
MicroSD
Type: SDHC
End of line jumper
End Of Line resistor
120 ohm
Environment
Usage
Indoor
Temperature
-20°C to +70°C
Humidity
20 ~ 90% RH non-condensing
