Expanding the Epic System
58
Station
Number
Stn. 11
Stn. 12
Stn. 13
Stn. 14
Line 1
Shared
Shared
Shared
Shared
Line 2
Shared
Shared
Shared
Shared
Line 3
Shared
Shared
Shared
Shared
Line 4
Shared
Shared
Shared
Shared
Users
Name
Michael
Helen
Sarah
Adam
Station
Number
Stn. 11
Stn. 12
Stn. 13
Line 1
Shared
Shared
Shared
Line 2
Shared
Shared
Shared
Line 3
Shared
Shared
Shared
Line 4Users
Name
Michael
Helen
Sarah
Private Lines
You may connect private lines to Lines 2, 3 or 4 at each station. A private line is a telephone num-
ber that is connected to just one station. You can have up to three private lines at each telephone.
The Chart below shows a few phones, with each one having its own private Line 4. This is a com-
mon configuration in Centrex environments.
Your Epic system can accomodate up to 16 stations. The maximum number of lines will depend
on how you choose to install the system.
Standard Configuration
This is the most common setup, and is the desired setup for most installations. This installation
is also called “square” in telephone terminology. This means that each telephone in the system is
connected to the same Line 1 telephone number, the same Line 2 telephone number, and so on
for Lines 3 and 4.
The chart below shows a simple square configuration. Note that since all lines are shared by all
the telephones, calls on any line can be transferred to any station. Also, calls put on hold at one
station can be taken off of hold at any other station.
Private
(555-2380)
Private
(555-7516)
Private
(555-7783)
Tel #555-1883
Tel #555-2870 Tel #555-3847 Tel #555-8698
Tel #555-1883
Tel #555-2870 Tel #555-3847 Tel #555-8698
ET4000 UG for PDF v8 062502.qxd 6/25/02 12:52 PM Page 68
