TMQ AP9 Autopilot (V6.0 - 965) Page 15 of 51 31/1/2017
Hand Remote Auto Steer
(AP9 special mode set to r-1)
To engage auto steer mode with Hand Remote Unit
· Switch AP9 to STANDBY, AUTO or POWER STEER
· Set remote knob to centre position
· Switch remote switch to AUTO
· Pilot locks on to boat heading as for normal autopilot
· Change course by +/- 90 º by rotating knob
Note: If remote switch is already in the AUTO position, move switch to OFF and then
back to AUTO .
To disengage auto steer mode with Remote Unit
· Switch remote switch to OFF
· Pilot is now in STANDBY mode
· Boat is now steered manually
To disengage remote auto steer mode with Main Control
· Select STANDBY, AUTO or POWER STEER on the AP9
· Boat is now steered from the Main Control panel
Hand Remote Power Steer
To engage power steer mode with Hand Remote
· Switch AP9 to STANDBY, AUTO or POWER STEER
· Set hand remote knob to centre position
· Switch remote switch to POWER STEER
· Boat is in manual control
· Steer boat by rotating knob
Note: If remote switch is already in the POWER STEER position, move switch to OFF
and then back to POWER STEER
To disengage power steer mode with Remote Unit
· Return remote unit course knob to centre
