TMQ AP9 Autopilot (V6.0 - 965) Page 16 of 51 31/1/2017
· Switch remote switch to OFF
· Pilot is now in STANDBY mode
· Boat is now steered manually using helm
To disengage remote power steer by Main Control
· Select STANDBY, AUTO or MAIN on AP9 main Control
· Boat is now steered from the Main Control panel
Important!!
The remote unit course knob (or steering lever) must be returned to centre before leaving
remote power steer mode. If not, auto mode or GPS mode will not steer accurately.
Steering Lever & Electric Helm Steering
(AP9 must be set for the correct special remote mode - see page 58)
Steering Levers and Electric Helms provide full follow up steering. A steering lever or
electric helm operates in a similar way to a hand remote control. However, the method
of operation will depend on the special remote mode set.
To Engage Steering Lever or Electric Helm
· Press select switch (or toggle select switch)
· Steer boat using lever or wheel
Note: Some internal remote mode settings allow for power steering at turn on, eg:
Electric helm wired to Wheel input at T7 terminal clock
To disengage Steering Lever or Electric Helm
· Press select switch
· Steer boat manually
