TMQ AP9 Autopilot (V6.0 - 965) Page 8 of 51 31/1/2017
OR Enter a course by pressing keypad numbers (eg: 350)
· Press GOTO
· Pilot will steer boat to course set (eg: 350º)
· Display will show course set (eg: 350)
Possible alarm
· Off course (more than 045º) or amount of “off course” as set by the operator.
Alarm pattern is 0.2 second on, 0.2 second off. The OFF COURSE light blinks
on and off at the same rate as the audible alarm
· Watch alarm (if set). Alarm pattern is 1 second on, 1 second off until reset by
pressing TIMER
Power Steering Mode
Engaging Power Steering Mode
· Press POWER button
· A beep will sound
· Power light will be lit
· Pilot will move rudder to centre position (midships)
· Steer boat by rotating large control knob
· Pilot can move rudder to the limit set
· Amount of rudder applied depends on amount of knob rotation
· Steer by using remote control (if fitted) when selected
Notes:
1. There are many variations on power-steering with a remote unit (eg: Electric
Wheel or Steering Levers). Refer to your dealer or TMQ Electronics. Some
information is available in the diagrams detailing remote unit operation and
connections on pages 20 and 43
2. If your vessel requires counter-rudder* while steering in auto mode, you may
wish to set the counter rudder control to "1" (ie: disabled) while using power-
steer.
* Refer to Counter Rudder settings on page 16
GPS Mode
Autopilot must be interfaced to a GPS generating NMEA 0183 data output. A route has to
be selected on the GPS (refer GPS manual).
