TMQ AP9 Autopilot (V6.0 - 965) Page 4 of 51 31/1/2017
Introduction
Warning
AUTOMATIC PILOTS ARE DESIGNED TO BE A NAVIGATIONAL AID AND
SHOULD NEVER BE LEFT SOLELY IN CHARGE OF THE VESSEL. AN
ADEQUATE WATCH SHOULD BE MAINTAINED AT ALL TIMES.
IT IS RECOMMENDED THAT THE AUTOPILOT NOT BE USED WHILE
NAVIGATING IN RESTRICTED WATERWAYS AS WATER CURRENTS, WIND
CHANGES OR RADIO TRANSMITTER INTERFERENCE MAY AFFECT VESSEL
COURSE SUFFICIENTLY TO ENDANGER YOUR OWN OR OTHER VESSELS.
Overview
The TMQ AP9 autopilot is a hybrid of digital and analogue technology to give the best
features - excellent steering characteristics with digital compass display, keypad course
input, GPS and gyro interfaces and manual controls for adjusting parameters to suit any
boat.
The AP9 system comprises the following essential components:
· Control Unit
· Compass or Compass Top Sensor
· Rudder Feedback Unit
· Rudder drive system
Optional Components:
· Hand or active Remote
· Second remote control display
· Steering lever or electric helm
· Rudder angle indicator
· External alarm
The autopilot can control movement of the rudder through a mechanical drive motor,
reversing hydraulic pump, solenoid valves on a constant running pump or relays. The
motor outputs have been carefully designed to work with a wide range of motors; for more
information on drive units, consult your dealer or TMQ Electronics.
