Installation of Remote Units
Hand and Active Remotes use a small clip bracket for mounting.
Steering Levers are normally mounted in-dash. For a TMQ steering lever this will
require a 90mm hole to be cut for mounting plus a position for a push button selection
switch (if used). Other steering levers as required.
The units are very robust and either of these may be mounted where it is subject to
occasional splashes of water. If mounted in direct sunlight, the decal may fade.
Hand Remote
· Select a position for the Hand Remote bracket
· Install the bracket and attach the remote
· Route the cable to the AP9 control position
· Connect the remote cable internally to T5 Remotes of AP9
· When the AP9 is switched on, test the remote operation
Steering Lever (TMQ)
· Select a position for the Steering Lever
· Cut a 90mm clearance hole for mounting the Lever
· Secure the steering lever with two screws
· Fit selection switch adjacent to lever (if used)
· Route the cable to the AP9 control position
· Connect the cable internally to terminal strip T4 Remotes socket (or terminal strip
T2 Wheel depending on the special mode of operation set in the AP9)
Wheel Input Terminals – T2
r-3 The input is active in “STANDBY” mode . Pressing POWER will
engage the encoder.
r-4 The input is active in “POWER” mode. The POWER control knob
(front panel) button is not active
