13
6. Unit operation
Creating a unit
1. Select from the menu bar Unit → New... to open the Unit Configuration window.
2. In the Unit Configuration window, first input the name of the unit then select a unit ID.
3. Select the number of inputs and outputs from among 2 x 6, 2 x 8, 2 x 10, 4 x 6, 4 x 8, and 6 x
6. The initial value is 2 x 6. When using an already existing template file, select "Create from
Template". You can directly input a filename, or you can make a selection from the dialog box,
which can be displayed by clicking the
part.
