11.3. FV-200RF-AS Microphone Receiver Panel
Power Source
Usable power supply unit : FV-200PS-AS
24 V DC (operating range: 19.5V ~ 27V), M3 Screw terminal
Current Consumption 230mA (rated), 130 mA (standby)
No. of Zone Groups in Speaker
Selector
Max. 10(SS-2010, SS-1010R, SS-1010)
Control Output
55 outputs, No-voltage make contact output, removable
terminal block (6 pins)
Priority Control for
Remote Microphone
Last-in-1st-out priority/1st-in-1st-out
priority/
individual priority
(s
electable)
Audio Output
0 dB*, unbalanced, Removable terminal block (2pins)
Usable Remote Microphone
RM-200M
Remote microphone extension unit : RM-210 (Max.4 unit)
No. of Connectable to Remote
Microphone
Max. 4, RJ-45 Connector
Maximum Cable Distance
Total 800 m
S/N Ratio
Over 60 dB
Distortion
Under 1% (1kHz, rated output)
Operating Temperature
0
to +40
Operating Humidity Under 90% RH (no condensation)
Finish
Panel: Aluminium, black, alumite
Dimensions 482 (w) × 44 (h) × 320 (d ) mm
Weight
2.8 kg
Note:
* 0 dB = 1V
The design and specification are subject to change without notice for improvement.
Accessory
Removable terminal plug (2 pins) ..................................... 2
Removable terminal plug (3 pins) ..................................... 1
Removable terminal plug (6 pins) ..................................... 10
LED Indicator Power (Green) , Error (Red)
