11.5. FV-224PA-AS 240W Power Amplifier Panel
Power Source
AC: 220 ~ 230 V AC, 50/60Hz
DC: 24 V DC (operating range: 19.5V ~ 27V)
M4 screw terminal, distance between barriers: 12 mm
Power Consumption
AC at rated output : 565W (Condition : AC 230 V)
AC at no signal : 22 W
IEC60065 : 245W
DC at rated output : 15 A (Condition : DC 27 V)
DC at no signal : 0.3 A
IEC60065 : 5.8 A
Rated Output
240 W
Input
2 inputs, 0 dB*, 20 k , balanced, removable terminal plug (3 pins)
Input module VP-200VX (Option)
Impedance
21 (70V), 42 (100V)
Speaker Output
M4 screw terminal, distance between barriers: 12 mm
Control Output
Fault output Make: Normal, Break : Error or Power Off
S/N Ratio Over 60 dB
Total Harmonic Distortion Under 1% (1kHz, 1/3 rated output)
Frequency Response
80Hz ~ 15kHz, ± 3dB, 1kHz
Ventilation Fan Cooling
Panel Indicator Power (Green)
Signal (Green)
Peak (Red)
Fault (Red)
Operating Temperature
0 °C to +40 °C
Operating Humidity
Under 90% RH (no condensation)
Finish
Panel: Aluminium, black, alumite
Dimensions
482 (w) x 88.4 (h) x 337.2 (d) mm
Weight
13.4kg
Note:
* 0 dB = 1V
The design and specification are subject to change without notice for improvement.
Accessory
Removable terminal plug (3 pins) ..................................... 3
Option
VP-200VX Input module.
Current Consumption
