3. FEATURES
4. INSTALLATION PRECAUTIONS
FV-200PS-AS
FV-200PS-AS
FV-200PS-AS
(FV-200PS-AS)
DC
DC POWER SUPPLY PANEL FV-200PS-AS
AC
The required power volatge for this system is 220~ 230V AC. Calculate the total combined power consumption of all
equipment in the system to ensure sufficient power capacity. Note that the system may not work properly due to
breaker cutoff or power voltage drops when the total supply voltage is insufficient.
/FV-248PA-AS 4 F00)
When mounting the FV-200PS-AS and FV-224PA-AS or FV-248PA-AS or FV-248PA-AS 4 F00 in an equipment
rack, mount a Perforated Panel larger than 1U size* j
ust above and below each component, as shown in the
following figure.
