FEATURES & CONTROLS
31
1 – Fuel Gauge
2 – Speedometer/Odometer
3 – Charge Meter/Voltmeter Gauge
4 – Coolant Temperature Gauge
5 – Indicator Light Cluster (see page 34)
6 – Map Light (if so equipped)
7 – Glove Box
8 – 12V Accessory Plug
9 – Master Switch
Console
1 2 3 5 4 5 6 7
9 8
Console
Fuel Gauge (1)
When the indicator needle nears the E (empty) mark, refuel at
the earliest opportunity.
12-Volt Accessory Plug (8)
The 12-volt receptacle is a standard automotive 12-volt auxiliary socket.
Master Switch (9)
When you must stop the operation of the vehicle in emergency situations, use of the master switch will disconnect battery power from the vehicle.
Master Switch Operation:
1. The “L” shaped key points left for regular operation.
2. In order to cut off power, turn the key counterclockwise to a vertical position.
3. The “L” shaped key can be removed from its holding base in either position.
