TOMCAR TM2 - Wheel Removal; Wheel Installation

MAINTENANCE & LUBRICATION
93
Tires and Suspension
Wheel Removal
1. Stoptheengineandlocktheparkingbrakeinthehorizontalposition.
2. Place an obstacle behind the rear wheels (or behind whatever wheels are touching the ground if you are replacing a rear wheel).
3. Loosen the wheel nuts slightly.
4. Elevate the side of the vehicle by placing a suitable jack under the frame.
5. Remove the wheel nuts. Remove the wheel.
Wheel Installation
1. With the parking brake locked, place the wheel in the correct position on the wheel hub. Be sure the valve stem is toward the outside
and rotation arrows on the tire point toward forward rotation.
2. Attachthewheelnutsandnger-tighten.
3. Carefully lower the vehicle to the ground.
4. Tightenthewheelnutsrmly.
