Filter Systems
1
4
3
Rear Air Filter
1 – Air Filter Housing
2 – Filter (not visible in picture)
3 – Cover
4 – Clamps
AlwayscheckandchangetheairlterattheintervalsoutlinedinthePeriodic
Maintenance Chart.
1. Lift the cargo box and locate the air box on the right-hand side.
2. Removeandinspectthelterfordebris.Checkfortearsordamage.Tapgentlyoncleanareawiththeairlterelement.
(Lookintothelightthroughthelterelement.Ifnolightisvisible,thenthelterisclogged.Replaceasneeded.)
3. Reinstallthelterwiththearrowpointingtowardtheengineandsecurethecoverknob.
4. Reassemble all components.
Itisrecommendedthatyoureplacetheairlterafterafteritssecondcleaning.
To clean the cartridge, gently tap on the end with the handle of a screw driver (replace cartridge if it is very dirty or damaged).
AlwayscheckandchangetheairlterattheintervalsoutlinedinthePeriodicMaintenanceChart.
CAUTION
Donotusepressurizedairorsolventstocleanthelter.Pressurizedairandsolventsmaydamagethelter.
Operationofthevehiclewithoutanairltercancauseenginedamage.Alwaysreinstalltheairlterafterremovingitforservice.
Service to the engine should only be performed once the engine cools to the surrounding outside tempurature.
Fuel Filter
Your TOMCAR
®
vehicleisequippedwithin-linefuellters.HaveyourqualiedTOMCAR
®
service representative replace it at the intervals
outlinedinthePeriodicMaintenanceChart.Donotattempttocleanthefuellter.
Air Filter Housing
