MAINTENANCE & LUBRICATION
82
Continuous Variable Transmission (CVT) System
CVT Belt Tension
Always check CVT belt tension and replace if required at the intervals outlined in the Periodic Maintenance Chart.
1.
Make sure the belt is not dried/cracked.
2.
When you apply pressure on the belt from the top and bottom, the gap between them should be between 2 - 2.75 in. (5 - 7 cm).
3.
Ifthebeltisloosened,contactyourqualiedTOMCAR
®
service representative to tighten the belt.
CVT Belt Tension
CVT Drying
•
When you cross deep water the belt may get wet, which can cause it to lose the majority of its grip, and it can slip.
•
When leaving water, drive normally. The belt will dry and get normal grip back on its own.
•
During the drying process, it is normal to see water vapor and hear a squeal. No special maintenance is required.
