Lubrication Recommendations
MAINTENANCE & LUBRICATION
Rear Area
Rear Axle (RHS) Rear Axle & CVT (LHS)
1 – Rear Right Drive Axle Lubricating Point 1 – Rear Left Drive Axle Lubricating Point
2 – Rear Right Drive Axle Lubricating Point 2 – Rear Left Drive Axle Lubricating Point
3 – CVT Lubricating Point
(Engine removed from picture for clarity)
68
