Tomey AL-4000 User Manual

3-79 䕔 
3.6.3 Gain setting
Settings made here are only effective for the eye
currently selected. Settings cannot be made for
both eyes simultaneously. Complete necessary
settings for each eye.

Adjust the waveform height according to the gain settings. The gain and
the waveform height increases as the gain value increases.
1) Turn the gain adjustment knob (1) on the exterior of the instrument
to set the gain. The setting is shown in the gain field (2) on the
monitor.
(Fig. 2)
(2)
(Fig. 1)
(1)
