2-4
2.3 Sides of the main unit
(1) AC adapter/footswitch connector
Connect the AC adapter and footswitch here.
(2) Maintenance switch
Our service personnel use this switch for maintenance.
(3) Cable hook
Wind the probe cable that can be stored in the main unit here.
(3)
(1)
(2)
