45
The setting will be immediately effective. But this state
will not saved if choose “Exiting without saving”;
“Saving and exiting” should be implemented if this
setting needs to be effective after restarting.
Default Setting: 5
Power-up State (PuP)
The “PuP” menu option allows user to configure
the power-up state of the LCR meter, allowing user to
restore settings saved into internal EEPROM memory
at power-up. The storable settings are as follows:
• Primary function mode (e.g. L/C/R)
• Secondary function mode (e.g. D/Q)
• State of auto LCR
• Series/parallel equivalent mode
• Test frequency
• Tolerance mode
• Reference value for Tolerance mode
• Measurement rate
In the utility menu, Press the and arrow keys
to select “PrE” or “SEt”. PrE means to preserve the
previous setting while SEt means to save the current
parameter, that is, cover the previous data.
