Topcon 3D-MC - Non Quick Release Attachment;Bucket Sensor Installation

Attachment/Bucket Sensor Installation
2-3
P/N: 7010-1006
Installation
Non Quick Release Attachment/Bucket Sensor
Installation
The recommended location for the TS-i3 Attachment/Bucket Sensor is on the inside of the
Bucket Snap-on Well.
Figure 2-2: Recommended Placement of TS-i3 Attachment/Bucket Sensor
Mount TS-i3
Attachment/Bucket
Sensor Here
Bucket Snap-on Well
