Topcon 3D-MC User Manual

GNSS Antenna, Mount, and Mast Installation
2-8
P/N: 7010-1006
Installation
.
Figure 2-7: Installing the Strain Relief Bracket
5. Repeat steps 3 and 4 for the second antenna mast.
Ensure enough cable is routed through the bracket, so that the cable can be looped
over and threaded into the bracket if or when the antenna is removed from the Wheel
Loader (Figure 2-7).
GNSS Antenna
Mast
Strain Relief Bracket
Cable
Loop
GNSS
Antenna Cable
Bolt (2)
Strain Relief Bracket
