Topcon ALADDIN HW3.0 User Manual

ALADDIN - User manual Rev. 19 EN of 10/07/2019
10
2.1 Electromagnetic compatibility
2.1.1 EM Emission
The ALADDIN HW3.0 device fulfills requirements of IEC 60601-1-2 4th Edition:
Emission limit
Standard
Compliance
Conducted and radiated RF
CISPR 11
Class B
Harmonic distortion
IEC 61000-3:2
Class A
Voltage fluctuations/ flicker emissions
IEC 61000-3:3
Compliant
2.1.2 EM Immunity
The ALADDIN HW3.0 device fulfills requirements of IEC 60601-1-2 4
th
Edition:
Immunity test
Standard
Test level
Electrostatic discharge (ESD)
IEC 61000-4-2
 8kV contact
 15kV air
Electrical fast transient/Burst
IEC 61000-4-4
2kV
100kHz repetition frequency
Surges
IEC 61000-4-5
1kV common mode
2kV differential mode
Rated Power frequency
magnetic field
IEC 61000-4-8
30 A/m
Conducted disturbances induced
by RF fields
IEC 61000-4-6
Level
Frequency
Modulation
3V
150kHz÷80MHz
1kHz 80% AM
6V
6,765MHz÷6,795MHz
1kHz 80% AM
6V
13,553MHz÷13,567MHz
1kHz 80% AM
6V
26,957MHz÷27,283MHz
1kHz 80% AM
6V
40,66 MHz ÷ 40,70 MHz
1kHz 80% AM
Radiated RF EM fields
IEC 61000-4-3
Field (V/m)
Frequency
Modulation
3
80MHz÷2700MHz
1kHz 80% AM
