1 NOMENCLATURE AND FUNCTIONS

1-2

Telescope

focusing knob

Plate level

Te le scope grip

Te lescope eyepiece

Instrument center

mark

Battery fixing knob

Vertical shuttle

Vertical jog

Horizontal shuttle

Horizontal jog

Adjusting screws for

circular level

Instrument height

mark

Centronics

connector

Tribrach fixing lever

Circular level

Power switc

h
