5.6 Offset measurement (OFFSET)
There are four offset measurement modes in the Offset Measurement.
• Angle offset
• Distance offset
• Plane offset
• Column offset
Offset Measurement Menu
[F2](OFFSET)
Programs
F1 LINE
p 7/7
F2 OFFSET p
F3 EXT.LINK p
MORE
OFFSET MEASUREMENT
1.ANGLE OFFSET
2.DIST. OFFSET
3.PLANE OFFSET
4.COLUMN OFFSET
ANGLE OFFSET
HR: 87°55'45"
HD: 20.000 m
VD: 5.000 m
NEXT SD NEZ REC
[F4](REC)
ANGLE OFFSET
HR: 87°55'45"
HD: 20.000 m
VD: 5.000 m
> REC ? YES NO
[F5](YES)
ANGLE OFFSET
HR: 87°55'45"
HD: 20.000 m
VD: 5.000
<REC>
m
• Outputting the Measurement Data
The results of offset measurement can be output to external device.
In offset measurement mode, the [F4] soft key which assigned (REC) will appear in measured r
esult display.
• Distance measurement mode of the offset measurement
Offset measurement will be done by N-time fine measurement mode.
