Topcon GPT-8005A - Communication Setup (Continued); Setting Cable (RS-232 C) Parameters

5 PROGRAM MODES
5-24
3
Select communication course by pressing the
[F3](↑) or [F4](↓) key.
(Sample setting :RC)
[F3]
or
[F4]
4
Press the [F1](SET) key to decide.
[F4]
● To c ancel the setting, press the [F6](EXIT)key or the [ESC] key.
CABLE/RADIO MODEM/RC
RC
SET
↑ ↓ EXIT
Setting
1 CABLE/RADIO MODEM/RC
2 PARAMETER(CABLE)
3 PARAMETER(RC)
4 PARAMETER(RADIO MODEM)
Operating procedure Operation Display
Execute Section 5.7.1“Starting compatible
communication program of AP-L1A” to start
[EXT.LINK] of compatible communication
program of AP-L1.
1
Press the [F2](Setting) key.
[F2]
EXTERNAL LINK
1 Execute
2 Setting
Setting
1 CABLE/RADIO MODEM/RC
2
3 PARAMETER(RC)
4 PARAMETER(RADIO MODEM)
(2)Setting Parameters of Cable (RS-232C)
In case connecting Topcon's designated wireless modem, simply select communication course as
"RADIO MODEM" it is enough to do setting of parameter automatically.
In case connecting personal computer or other than Topcon's designated wireless modem, it is
required to do parameters setting for RS-232C before using.
Parameters
1) SPEED (Baud rate)
Sets communication speed
Set items: 1200, 2400, 4800, 9600bps
2) BIT FORMAT
Select the communication format.
Set items:
Bit length : 7 : D7, 8 : D8
Stop bit : 1 :S1, 2 :S2
Parity bit : NONE, ODD, EVEN
3) DELIMITER (Terminate)
Selecting CR (Carriage return), or LF (Line feed) will be added at the end of data.
Set items:
ETX, ETX+CR, ETX+CRLF
4) RTS (Control of signal line)
Select default output of signal line
Set items:
Hi : High level (Normal)
Low : Low level (It becomes High level only when data are transmitted.)
5) REC TYPE
Select the option to record the data for the distance measurement.
REC-A : Measure the distance again and record the updated distance.
REC-B : Record the data for the last distance measurement on the display.
