5 PROGRAM MODES
5-26
4) REC TYPE
Select the option to record the data for the distance measurement.
REC-A : Measure the distance again and record the updated distance.
REC-B : Record the data for the last distance measurement on the display.
(4)Setting Parameters for Radio Modem
Set the parameters for Radio Modem.
Parameters
1) Channel (Only for certain market)
Sets communication channel
The same channel must be set for GPT-8000A series and Radio Modem.
Set channels : A, B, C......
Operating procedure Operation Display
Execute Section 5.7.1“Starting compatible
communication program of AP-L1A” to start
[EXT.LINK] of compatible communication
program of AP-L1.
1
Press the [F2](Setting) key.
[F2]
2
Press the [F3] key to select [3 PARAMETER
(RC)].
[F3]
3
Select a channel by pressing the [F3](↑) or
[F4](↓) key then press the [F1](SET) key.
[F3]
or
[F4]
[F1]
4
Select Terminate by pressing the [F3](↑) or
[F4](↓) key then press the [F1](
SET) key.
[F
3]
or
[F4]
[F1]
5
Select Retry by pressing the [F3](↑) or [F4](↓)
key then press the [F1](SET) key
[F3]
or
[F4]
[F1]
6
Set REC TYPE in the same way.
[F3]
or
[F4]
[F1]
● To c ancel the setting, press the [F6](EXIT)key or the [ESC] key.
EXTERNAL LINK
1 Execute
2 Setting
Setting
1 CABLE/RADIO MODEM/RC
2 PARAMETER(CABLE)
3 PARAMETER(RC)
4 PARAMETER(RADIO MODEM)
CHANNEL
1
SET ↑ ↓ EXIT
TERMINATE
ETX
SET ↑ ↓ EXIT
RETRY
Standard
SET
↑ ↓
EXIT
REC TYPE
REC-A
SET ↑ ↓ EXIT
Setting
1 CABLE/RADIO MODEM/RC
2
PARAMETER(CABLE)
3 PARAMETER(RC)
4 PARAMETER(RADIO MODEM)
