146

14 BATTERY SYSTEM

In case of On-board battery

In case of External battery

BT-65Q

IS series

Charging

BT-65Q

Charging time

BC-30

Quick charge

for AC100V-240V use

Approx. 5h

Note:

Use only recommended batteries or external power source.

Use of batteries or an external power source not recommended by us

may result in equipment failure.

External battery
