Topcon IS01 - Data Memory Card

55
2 PREPARATION FOR MEASUREMENT
2.8 Data Memory Card
• How to insert a data memory card(CF card)
1
Push up the card cover lever to open the card cover.
2
Insert a data memory card.
3
Close the card cover.
• How to extract a data memory card
1
Push up the card cover lever to open the card cover.
2
Pull down the card guide.
Note: Hold the card with your hand to protect the card against falling.
3
Extract the card.
4
Close the card cover.
Card cover
Card cover
lever
Data memor
y
card
Card guide
Please make sure you have the front and back of the CF cards facing correctly when inserting into
the card slot.
If you forcibly insert the card incorrectly, the pin at the card slot may be damaged and cause a
breakdown.
Front of the card
Please insert straight up into the card slot.
If you forcibly insert the card at an angle, the pin at the card slot may be damaged and cause a
breakdown.
