Topcon RL-H2Sa - Control Panel Overview; Instrument Set-up Procedure

10
Control Panel
Enter key
Battery indicator
Mask key
Auto/manual leveling key
Manual mode lamp
Power key
Auto leveling indicator
Rotation control key
Y-axis key
Arrow keys
Y-axis grade display
Masking direction indicator
Rotation speed
(Arrow key for Mask
quadrant 4)
(Arrow key for Mask
quadrant 2)
• Changes rotation speed
• Changes grade setting
• Controls mask quadrants 1 and 3
X-axis grade display
X-axis key
