Topcon RL-H2Sa - Entering Grade

18
Entering Grade
The laser beam can be sloped in either the X or Y axis (single slope) or both axes (com-
pound slope).
Grade range: Single axis: -8.000 to +8.000%, Dual axes: |X| + |Y| ≤ 10.000%
Single Axis
Dual Axes
Compound slope
Ｙ
Ｘ
ｒｐｍ
１００
ＭＡＮＵ
×
ＰＯＷＥＲ
％
％
ＯＮ
ＥＮＴ
X axis
Y axis
X axis
Horizontal
Y axis
Horizontal
Minus (-)
Plus (+)
Plus (+)
Plus (+)
Minus (-)
Plus (+)
Minus (-)
Minus (-)
Control Panel side
+8%
+8%
+8%
+8%
- 8%
- 8%
- 8%
- 8%
