5.1- GENERAL INSTRUCTIONS
THE ACTUATOR INSTALLATION CAN BE PERFORMED EXCLUSIVELY BY COMPETENT
AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE PROFESSIONAL AND
TECHNICAL REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF
INSTALLATION.
THE ACTUATOR PERFORMANCE MUST BE SUFFICIENT TO ASSURE THE CORRECT
MOVEMENT OF THE WINDOW. IT IS COMPULSORY TO VERIFY THE THRUST OR
TRACTIVE FORCE ACCORDING TO THE TYPE AND WEIGHT OF THE WINDOW (PAR. 3.4).
IT IS FORBIDDEN TO EXCEED THE LIMITS SET IN TAB. 1 CONCERNING TECHNICAL
DATA (PAR. 3.3).
THE ACTUATOR INSTALLATION MUST BE PERFORMED EXCLUSIVELY WITH CLOSED
WINDOW OR SKYLIGHT.
BEFORE PERFORMING THE INSTALLATION OF THE ACTUATOR ON BOTTOM HUNG
WINDOWS, VERIFY THAT ON BOTH SIDES OF THE WINDOW TWO COMPASS STROKE
LIMIT DEVICES ARE INSTALLED IN ORDER TO AVOID THE ACCIDENTAL FALL OF THE
WINDOW.
FOR CORRECT OPERATION OF THE ACTUATOR, THE WINDOW FRAME MUST HAVE A
MINIMUM HEIGHT VALUE INCLUDED IN THE RANGE STATED IN TABLE FIG. 7a FOR TOP
HUNG ASSEMBLY, IN TABLE FIG. 7b FOR BOTTOM HUNG ASSEMBLY, AND IN TABLE FIG.
7c FOR THE DOME ASSEMBLY.
THE STROKE SELECTION HAS TO BE CARRIED OUT WITH SWITCHED OFF ACTUATOR
ONLY BY COMPETENT AND QUALIFIED TECHNICAL PERSONNEL.
VERIFY THAT THE POSITIONS OF THE LABELS LOCATED ON THE QUICK COUPLING
CORRESPOND TO THE LABELS ON THE ACTUATOR: RED LABEL WITH LETTER “A”
FOR THE TOP HUNG ASSEMBLY, GREEN LABEL WITH LETTER “B” FOR VERTICAL
ASSEMBLY.
VERIFY THAT DISTANCE “D” BETWEEN THE ACTUATOR SHELL AND THE CHAIN END
(FIG. 7a/7b/7c) IS GREATER THAN 5 mm.
IF THE WING AND THE FRAME ARE COPLANAR PROCEED WITH THE ASSEMBLY
ACCORDING TO FIG. 7.
THE FITTING SURFACE FOR THE ARS RAPID COUPLING DEVICE MUST BE PERFECTLY
FLAT AND/OR SMOOTH.
