TOPP C20 User Manual

5.5- ELECTRIC CONNECTIONS (Wiring diagram)
THE CONNECTION OF MODEL C20/24V HAS TO BE CARRIED OUT WITH VERY LOW
VOLTAGE SAFETY FEEDER PROTECTED AGAINST SHORT CIRCUIT.
THE ELECTRIC CONNECTION OF THE ACTUATOR CAN BE PERFORMED ONLY BY
COMPETENT AND QUALIFIED TECHNICAL PERSONNEL FORESEEN BY THE LAW IN
FORCE IN THE COUNTRY OF INSTALLATION WHO CAN ISSUE TO THE CUSTOMER A
DECLARATION OF CONFORMITY FOR THE CONNECTION AND/OR PLANT CARRIED
OUT.
BEFORE PERFORMING THE ELECTRIC CONNECTION OF THE ACTUATOR, VERIFY THE
CORRECT INSTALLATION ON THE WINDOW.
THE MAINS TO WHICH THE ACTUATOR IS CONNECTED MUST COMPLY WITH THE
REQUIREMENTS OF THE LAWS IN FORCE IN THE COUNTRY OF INSTALLATION, AS
WELL AS SATISFY THE TECHNICAL FEATURES GIVEN IN TAB. 1 AND ON THE RATING
PLATE AND THE “CE” MARKING (PAR. 3.1), AS WELL AS BE EQUIPPED WITH A
SUITABLE “EARTHING PLANT”.
THE SECTION OF THE MAINS CABLES MUST BE PROPERLY SIZED ACCORDING TO THE
ABSORBED ELECTRIC POWER (SEE RATING PLATE AND “CE” MARKING).
ANY TYPE OF ELECTRIC MATERIAL (PLUG, CABLE, TERMINALS, ETC.) USED FOR THE
CONNECTION MUST BE SUITABLE FOR THE USE, WITH “CE” MARKING, AND
COMPLYING WITH THE REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN THE
COUNTRY OF INSTALLATION.
TO ASSURE AN EFFICIENT SEPARATION FROM THE MAINS, IT IS COMPULSORY TO
INSTALL UPSTREAM OF THE DEVICE A TEMPORARY BIPOLAR SWITCH (PUSH-
BUTTON) OF APPROVED TYPE. UPSTREAM OF THE COMMAND LINE, IT IS
COMPULSORY TO INSTALL AN UNIPOLAR MAIN SWITCH WITH OPENING OF CONTACTS
OF AT LEAST 3 mm.
BEFORE MAKING ANY ELECTRICAL CONNECTIONS ON THE ACTUATOR, MAKE SURE
THE POWER SUPPLY CABLE IS NOT DAMAGED. IF THE CABLE IS DAMAGED, THEN IT
MUST BE REPLACED BY THE MANUFACTURER THROUGH THE TECHNICAL
ASSISTANCE SERVICE OR BY TECHNICAL OPERATORS.
5.6- COMMAND DEVICES
THE CONTROL DEVICES USED TO DRIVE THE ACTUATOR MUST ASSURE THE SAFETY
CONDITIONS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF USE.
1) MANUAL PUSH-BUTTON:
;
According to the different type of installations, the actuators can be driven by the
following control devices:
Bipolar switch button with central OFF position, with biased-off switch
24
C20
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
5- INSTALLATION
