3.6- USE LIMITS
The actuator has been designed and manufactured exclusively for the destination of
use given in par. 3.5, therefore, any other type of use is strictly forbidden in order to
assure in any moment the safety of the installer and of the user, as well as the efficiency
of the actuator itself.
IT IS STRICTLY FORBIDDEN TO USE THE ACTUATOR FOR IMPROPER USES, I.E. OTHER
THAN THE ONE FORESEEN BY THE MANUFACTURER (SEE PAR. 3.5).
IT IS STRICTLY FORBIDDEN TO INSTALL THE ACTUATOR ON THE EXTERNAL SIDE OF
THE WINDOW FRAME SUBJECT TO ATMOSPHERIC AGENTS (RAIN, SNOW, ETC.).
THE USE OF THE ACTUATOR IN ENVIRONMENTS WITH POTENTIALLY EXPLOSIVE
ATMOSPHERE IS STRICTLY FORBIDDEN.
IT IS COMPULSORY TO KEEP THE PACKAGE AND THE ACTUATOR OUT OF REACH OF
CHILDREN.
3.7- PACKAGE
Each package of the product (cardboard box) contains (Fig. 5):
• No. 1 Actuator equipped with power supply cable (with electric connector);
• No. 2 Window frame connection brackets (right-left) (Ref. A);
• No. 1 Bracket for bottom hung opening (Ref. B);
• No. 1 Adhesive drilling template (Ref. C);
• No. 1 Installation and use instructions (Ref. E);
• No. 1 Safety plate (Fig. 6);
MAKE SURE THAT THE ABOVE DESCRIBED COMPONENTS ARE CONTAINED IN THE
PACKAGE, AS WELL AS THAT THE ACTUATOR HAS NOT BEEN DAMAGED DURING
TRANSPORT.
SHOULD ANY ANOMALY BE DETECTED, IT IS FORBIDDEN TO INSTALL THE ACTUATOR,
AND IT IS COMPULSORY TO REQUIRE TECHNICAL ASSISTANCE FROM YOUR DEALER
OR THE MANUFACTURER.
THE PACKAGING (PAPER, PLASTIC, ETC.) HAS TO BE DISPOSED ACCORDING TO THE
LAWS IN FORCE.
• No. 1 Small parts package for aluminum windows (No. 2 screws for lateral fastening of
connection brackets to the window, No. 7 screws AF Ø 4,8 x 16 mm and No. 2 screws
AF Ø 4,2 x 19 mm for the fastening of the brackets to the window frame and for ARS
coupling fastening) (Ref. D);
• No. 1 ARS coupling release tool (Ref. D-1);
• No. 1 ARS coupling (Ref. D-2);
EX
C20
3- TECHNICAL DESCRIPTION
12
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
