Fig. 2a
48
34
286
342
15.1
362
10.3
64.5
4
2
1
3
5
Dimensions in mm
3.2- DENOMINATION OF THE COMPONENTS AND DIMENSIONS
LEGEND:
1) Power supply cable
2) Window frame connection brackets (right-left)
3) Actuator
4) Chain end
5) Electric connector
6) Switch I=240 mm; II=360 mm
C20
3- TECHNICAL DESCRIPTION
8
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
6
-
+
7
Min
(-)
Max
(+)
150 N
100 N
200 N
300 N
7)
Dip switch power
Thrust
force
Tractive
force
